300KG Automatic Door Opener
Drive door weight
≤ 500kg
Product Specifications
Single opening, double opening, linkage
Installation method
Top hanging, side hanging
Suitable for installing door materials
Pure glass doors, non restrained pot edge doors, aluminum alloy doors, this door and other door materials are not limited
Model
QT - K300
Product Features
BETTER STRUCTURE: No gearbox, using safer direct drive technology
SMOOTHNESS CONTROL: unit with Vector Control Algorithm, more smooth
SAFETY :Precise control of opening and closing force, rapid rebound reaction when encountering resistance, easy reverse push, safety anti-pinch
ULTRA QUIET :No transmission structure friction, the door machine runs comfortably and quietly
AUTO LEARNING: Self-learning stroke after power-on, adaptive control operation path, mobile phone debugging, low maintenance cost
EASY OPERATION :Support pre-factory debugging settings, convenient installation without threshold
Main Technical Parameters
QT- 68 Door Unit
Door Leaf Form: Single/Dual
Door Leaf Weight: 150kg*1/75kg*2
Applicable door materials: Glass doors, stainless steel edging door
Standard Track Length: 4.2m(cut)
Standard Belt Length: 8.5m(cut)
Standard Adaptive Door Width: Single 500mm ~ 2100mm Dual 500mm
Rated Power: 25W
Power Type: AC100-240V,50/60Hz
Standby Power: < 5W(No lock state)
Anti-pinch Force: ≤ 10N(Safe and no harm)
Open/Close Speed: 100~500mm/s(Adjustable)
Hold Time: 0 ~ 30s(Adjustable)
Ambient Temperature: -30℃ ~ 50℃
